Fantasea

18.8m Commuter Ferry

Details and Specifications of Fantasea (This design is available for construction)

This 18.8 meter commuter ferry was built and designed for Fantasea Cruises and is currently operational in the Whitsundays in Queensland Australia. This aluminium passenger catamaran is licenced to carry 130 passengers in USL Code Class 1D. The vessel is powered by twin Deutz 430 hp Diesel engines and has a top speed of over 25 knots.

Specifications
Length Overall 18.8 m
Beam6.2 m
Draught1.4 m
Fuel Tank2 x 1000 litres
Water capacity1 x 500 litres
Propulsion2 x 330 kw Deutz
Passengers140
Operational speed22 kt
Maximum Speed26 kt

Fantasea Gallery
